Used Carlson BRx7 RTK Package

The Carlson BRx7 is the latest receiver from Carlson, powered by Hemisphere technology. The BRx7 carries the latest Phantom P40 board that is designed to take advantage of all the available constellations and signals. This is the best performing receiver in multi-path environments on the market. When paired with the 30° tilt sensor this is the receiver that you can take anywhere to survey anything.

Additional product info

Detailed quote form

Request A Free Quote – Carlson BRx7

"*" indicates required fields

BRx7 Options

Select Receiver

Data Collection Options

Select Data Collection

Long-Range Options

Select Long-Range RTK

Desktop Software

Select Desktop Software


Select Accessories
Call In?
Receive text messages from us?

By submitting this form, you hereby agree to receive communications from Bench Mark

Product details

  • Triple Frequency Multi Constellation Receiver
  • Fix on Any Constellation
  • Best in Class Canopy Performance
  • Internal 1 Watt Satel Radio – 10 km Range
  • LTE Internal Cell Modem
  • 9 Hour Hot Swappable Batteries
  • 1.3 kg with Batteries

Package includes

  • Carlson BRX7 Rover
  • UHF Antennas
  • 2x Batteries
  • Adjustable 2m Pole


Carlson BRx7

The BRx7 is the latest and greatest GNSS receiver from Carlson, capitalizing on the best of the BRx5 and BRx6+: the compact, hot swappable batteries from the BRx5 and the robust RTK engine and great Satel radios from the BRx6+. But its great features don’t stop there; the BRx7 is known for its tilt shot ability, Hemisphere P40 board, plethora of constellations, performance under canopy, and impressive range. The BRx7’s reputation is gaining popularity in the market, competing even with well-established GNSS brands.


Tilt Surveying

There is nothing more practical and versatile than an internal tilt sensor- and with the BRx7’s design, you can get up to 60° of tilt, with 2 cm of compensation at 30° or 5 cm at 60°. Gone are the struggles of pole-levelling!


Better Performance

Because of its design with the Hemisphere Phantom P40 board, the BRx7 has access to an array of constellations and signals, allowing for performance and variety in multi-path environments. Some constellations and signals include: GPS; L1CA, L1P, L1C, L2P, L2C, L5, GLONASS; G1, G2, G3, P1, P2, Beidou; B1i, B2i, B3i, B10C, B2A, B2B, ACEBOC, GALILEO; E1BC, E5a, E5b, E6BC, ALTBOC, QZSS; L1CA, L2C, L5, L1C, LEX, IRNSS; L5 and Atlas.


Key BRx7 Features

  • Multi-Frequency, Multi Constellation Base Rover Capability
  • GPS, GLONASS, Galileo, Beidou, QZSS, IRNSS, SBAS, Atlas
  • Athena RTK Engine
  • Hot Swappable Batteries with 9 Hours of Life on Single Charge
  • Internal Wifi, Bluetooth, Cellular and UHF
  • Over GNSS Channels
  • 8 GB of Internal Storage
  • Static Capable
